wind turbine generator 5kw permanent magnet generator

FOB Reference Price:Get Latest Price
US $4,500-8,500 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Hengfeng
Model Number:
HF6.0-5000W
Type:
Wind Power Generator
Product name:
wind turbine 5kw
Max power:
7000w
Color:
Customer's Requirements
Blade Material:
FRP
Blade number:
3pcs
Rated wind speed:
8m/s
Rated rotor speed:
200r/m
Certificate:
CE/SGS/ISO9001.2008
Cable material:
copper & PVC
Supply Ability
Supply Ability:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
We use plywood case and film packing components.
Port
Qingdao
Lead Time :
15 days after payment
Product Description

wind turbine generator 5kw permanent magnet generator



Basic parameter



Power5000w
Blade diameter6.0m
Rated rotor speed200r/m
Rated speed 8m/s
Rated power 5000w
Max power7000w
Output voltage220v
Start up wind speed 3m/s
Work speed 3-25m/s
Security wind speed 50m/s
Height of tower9m
Top weight except tower285kg
Output controller systemcontroller,inverter
Suggested batteries and capacity12v,200AH,18PCS
Tower type∅133mm steel tube
Can spply power forsmallvillage,referigerator,washing machine,water pump,TV,electric fan,charge



Advantage



1.Generator: the machine shell and the stator we use the first pressure loading after the lower line immersion lacquer, better protection of copper wire, to avoid the damage caused by back pressure loading on the coil.

2.Revolving body: integral design with tail, adopting the center deviation design of the revolving body, adjusting the direction more flexibly and more effectively, protecting motor speed and blade carbon brush and slip ring.

3.The tail cylinder and the rotary body are integrated, which highlights the overall line type of the generator, and is more coordinated. The stern tube is fixed, so the tail plate protection is adopted. The design requirement is higher, all the technical parameters are more in place, and the protection of the excess wind speed is more coordinated and effective.

4.Blade adopts high-grade anti-corrosion, anti weathering steel, glass coating and high density fiber cloth, anti fatigue effect than other leaves increased more than fifty percent. The blade process is protected by the coating of the imported metal film, which effectively prevents the crack of the blade.



FREE STAND TOWER

Height of pole:9 m

Thickness: 8mm

Tower diameter: 420(mm)

Flange: 300*300*16 (mm)

Sections of tower:2

Material: Q235 Steel pipe

Surface treatment: hot-dip galvanized & plastic spraying



GUY WIRE TOWER

Height of pole: 9 m

Thickness: 6 mm

Tower diameter: 133(mm)

Flange: 200*200*10 (mm)

Sections of tower:2

Material: Q235 Steel pip

Surface treatment: painting against decaying



Packaging & Shipping

 We use plywood case and film to package product,and we also can respect your requirements.

package



Our Services



1.Reply your inquiry in 24  workig hours.

2.We can design and make procuts according to your requirements.

3.Our professional engineers can solve the problems in the process of use for you.

4.We use advanced technology and superior raw material to produce our products in order to ensure the quality of the products.

5.In the future ,we will be good parnter.

_12



Our other product

1.150w-500kw horizontal axis wind turbine

2.vertical axis wind turbine

3.controller,inverter,battery,permanent magnet generator,blade,etc.

4.solar panel

5.solar and wind hybrid system







Company Information

1.Qingdao Hengfeng Wind Power Generator Co.,Ltd is one of the leading wind turbine manufacturer

in China. Company start at 2004,Workshop covers more than 5000 square meters.It is about 1 hour by car to Qingdao Airport.The traffic is very convenient.

2. Our company owns advanced design and manufacture technology of wind turbine generators. We

also have wind solar hybrid system, we can design the system according the requirement from our

clients.

3.Our products have except to more than 43 contries,for example,Europe,Middle East,Southeast Asia,Australia etc.We have unrivalled experience and has built up a global reputation for their robust and reliable performance.

_05

work shop

target market





FAQ



1.Can I only buy parts not whole system?

 Yes,you can.

2. Are you manufacturer?

Yes,we are BV approved rubber products manufacturer in China.

3.Does installation easy?

We will provide you with detailed installation instructions.

4.How long is the life of the product?

20-25 years.
